PVC Food Tubing

Application area Usable for conveyance of beverages such as wine, fruit juices, lemonade,... more

Application area

Usable for conveyance of beverages such as wine, fruit juices, lemonade, mineral water, unfermented sweetened fruit juice, and alcoholic beverages up to 13 vol.-% alcohol, but not usable for milk and beer. The temperature of the conveyed beverages should not exceed +40 °C.

Product specification

Flexible and resistant material, resistant to aging and abrasion, rugged and pressure-proof, inside and outside smooth, hardly inflammable, sterilizable, no change of material by light or atmospheric oxygen, physiologically safe.

Technical specification

Material: PVC-P (polyvinyl chloride, monomere softener, Additive)

Colour: transparent

Shore hardness A: 77° ±3° (DIN 53505)

Temperature range: -10 to +60 °C, at +40 °C nearly atmospheric pressure

Tearing strength: 17 N/mm2

Elongation at break: >350 %

Surface resistance: 1011 Ohm

Tolerance: for internal diameter and wall thickness according to DIN 16940

Sterilization: sterilizable, at least 30 times, at +121 °C at normal pressure in hot air; the sterilization periods should not exceed 30 min. each

Regulations: manufactured in accordance with the recommendation of the Food Quality BgVO, KTW-C tested

No additional information available.
Item Image Inside Ø
mm
Außen-Ø
mm
Einheit
m
Price
Euro*
Buy
27280
6 9 5 27.00
27283
6 9 15 69.00
27278
8 12 5 33.00
27279
8 12 15 84.00
27281
13 19 5 69.00
27282
13 19 15 164.00
27284
16 20 5 95.00
27285
16 20 15 226.00
27287
19 26 5 107.00
27288
19 26 15 256.00
27290
25 33 5 159.00
27291
25 33 15 379.00
27293
32 40 5 178.00
27294
32 40 15 478.00
27296
32 42 5 206.00
27297
32 42 15 557.00
27299
38 48 5 299.00
27300
38 48 15 651.00
27302
40 48 5 249.00
27303
40 48 15 651.00
27305
40 50 5 284.00
27306
40 50 15 768.00
27308
50 60 5 327.00
27309
50 60 15 883.00
