NBR Chemical Tubing

Preview: NBR Chemical Tubing Preview: NBR Chemical Tubing
NBR Chemical Tubing
NBR Chemical Tubing


Description General Information
Description
Product specification Nitrile rubber of highest quality Excellent mechanical rubber-elastic... more
Close menu

Product specification

Nitrile rubber of highest quality

Excellent mechanical rubber-elastic properties, also at extreme bending radii

Best abrasion resistance

Very good thermal resistance

Very good resistance to oil, fuels, vegetable and animal oils, silicones, as well as dilute alkalis and acids at room temperature

Technical specification

Material: NBR (butadiene-acrylonitrile rubber)

Colour: black

Shore hardness A: 70° ±5°

Temperature range: -20 to +100 °C

Density: 1.44 g/cm3

Tolerances: ISO 1307, DIN 7715-40

General Information
more
Close menu
No additional information available.
