FEP Chemical Tubing - outside calibrated

FEP Chemical Tubing - outside calibrated

Application area Flexible tubings for conveyance of all kinds of liquid and gaseous media,... more

Close menu

Application area

Flexible tubings for conveyance of all kinds of liquid and gaseous media, also under pressure

Flexible pneumatic and hydraulic tubings

Usable also at increased temperature and under aggressive environmental conditions in the areas of machine and plant construction, precision engineering, medical engineering, biotechnology and physical-technical research laboratories.

Product specification

Metrically calibrated fluorine copolymer tubings, especially for use with THOMAFLUID^® plug-in couplings

Chemically inert, resistant to solvents, free of leachable components

Biocompatible and resistant to food

Flexible and resistant to bending

Pressure and temperature loadable

Technical specification

Material: FEP (fluoroethylene-propylene)

Colour: opal translucent

Shore hardness D: 55°

Temperature range: -40 to +150 °C

Tolerances outside Ø: 4 mm ±0.05 mm; 6 - 10 mm ±0.07 mm; 12 mm ±0.10 mm

Close menu

No additional information available.

Item	Inside Ø mm	Außen-Ø mm	max. Betr.-Druck¹ bar	max. Betr.-Druck² bar	min. Biegeradius mm	Einheit m	Price Euro*
47293	2,5	4	28	6	40	5	199.00
47294	2,5	4	28	6	40	25	583.00
47295	4	6	25	5	50	5	339.00
47296	4	6	25	5	50	25	840.00
47297	6	8	20	2,5	70	5	376.00
47298	6	8	20	2,5	70	25	939.00
47299	8	10	15	2	120	5	430.00
47300	8	10	15	2	120	25	1,074.00
47301	10	12	12,5	1,5	180	5	519.00
47302	10	12	12,5	1,5	180	25	1,271.00
