PP Chemical Tubing - Standard | Reichelt Chemietechnik

Product specification Very good dielectric properties Good temperature resistance Extremely... more

Close menu

Product specification

Very good dielectric properties

Good temperature resistance

Extremely good impact and notch impact strength

Thermoforming possible (e.g. for bending-off)

Good chemical resistance to oils, gasoline, and acids, at room temperature to most solvents. Unsuitable for permanent use with halogenated hydrocarbons

Technical specification

Material: PP (polypropylene)

Colour: translucent

Shore hardness D: 80°

Temperature range: -40 to +120 °C, for a short time +145 °C

Flammability rating: UL 94 HB

Regulations: FDA 21 CFR §177.1520

Close menu

No additional information available.

Item	Inside Ø mm	Außen-Ø mm	max. Betr.-Druck¹ bar	Einheit m	Price Euro*
19067	1,6	3,2	66	5	27.00
19068	1,6	3,2	66	15	74.00
19079	3,2	6,4	66	5	36.00
19080	3,2	6,4	66	15	91.00
19061	4,8	6,4	19	5	42.00
19062	4,8	6,4	19	15	107.00
19063	4,8	7,9	20	5	83.00
19064	4,8	7,9	20	10	151.00
19065	6,4	9,5	19	5	94.00
19066	6,4	9,5	19	10	171.00
19071	9,5	12,7	14	5	121.00
19072	9,5	12,7	14	10	225.00
19073	12,7	15,9	12	5	127.00
19074	12,7	15,9	12	10	234.00
19075	16	19	10	5	135.00
19076	16	19	10	10	255.00
