TPE Food and Drinking Water Tubing

Application area Drinking water supply and municipal water supply facilities, food industry... more

Close menu

Application area

Drinking water supply and municipal water supply facilities, food industry and industrial kitchens, beverage industry and dispensing systems, public festivals, trade fairs and other events.

Product specification

Highly flexible food and drinking water hose for transporting drinking water as well as alcoholic and non-alcoholic beverages and foodstuffs.

Suitable for drinking water, juices, milk, oil-water emulsions, soft drinks and alcoholic foods with an ethanol content of up to 50 vol-%, such as beer and wine.

Suitable for pressure applications due to double wall construction of TPE liner and TPE cover with integrated polyester thread fabric.

Physiologically safe and absolutely suitable for foodstuffs and drinking water, in accordance with the conformity regulations.

Low weight and highly flexible, even at low temperatures.

Limited UV resistance.

Technical specification

Material:

Liner: TPE (thermoplastic elastomer)

Reinforcement: Polyester thread fabric

Cover: TPE (thermoplastic elastomer)

Colour: dark blue, with white imprint

Temperature range: -30 to +70 °C

Max. operating pressure: 9 to 10 bar at +20 °C

Bursting pressure: approx. 3-fold operating pressure

Regulations: EU 10/2011 (A, B, C, D1), EG 1935/2004, KTW A and DVGW W270

Close menu

No additional information available.

Item	Inside Ø mm	Außen-Ø mm	max. Betr.-Druck bar	Platzdruck bar	min. Biegeradius mm	Gewicht kg/m	Einheit m	Price Euro*
343050	10	15	10	30	50	0,1	1	28.00
343051	10	15	10	30	50	0,1	5	108.00
343052	10	15	10	30	50	0,1	10	176.00
343053	12,3	17,5	10	30	70	0,125	1	32.00
343054	12,3	17,5	10	30	70	0,125	5	124.00
343055	12,3	17,5	10	30	70	0,125	10	202.00
343056	19	25,7	10	30	90	0,23	1	44.00
343057	19	25,7	10	30	90	0,23	5	170.00
343058	19	25,7	10	30	90	0,23	10	282.00
343059	25	32,8	9	27	110	0,36	1	59.00
343060	25	32,8	9	27	110	0,36	5	228.00
343061	25	32,8	9	27	110	0,36	10	370.00
