FPM Pump Tubing Fitted with 2 Stoppers

Preview: FPM Pump Tubing Fitted with 2 Stoppers Preview: FPM Pump Tubing Fitted with 2 Stoppers
FPM Pump Tubing Fitted with 2 Stoppers
FPM Pump Tubing Fitted with 2 Stoppers

Description General Information
Description
Product specification For peristaltic pumps with mini tubing cassettes. Fitted with two... more
Close menu

Product specification

For peristaltic pumps with mini tubing cassettes.

Fitted with two stoppers each for mounting in tubing cassettes; colour-coded for clearly organized use.

Technical specification

Material: FPM (fluorinated rubber TYGON®-F-5500-A)

Shore hardness A: 64° ±3°

Tolerance: DIN ISO 3302-1 E2

Fixed length: 178 mm, 2 coloured stopper, stopper distance 127 mm

General Information
General Information FPM For use in analytical technology, medical engineering, chemical... more
Close menu

General Information FPM

For use in analytical technology, medical engineering, chemical industry, biotechnology, laboratory technology and process engineering.

Extraordinary chemical resistance to hydrocarbons, mineral, vegetable, and animal oils, aromatic and chlorine containing solvents, many acids, alkalis, and oxidizing agents. Unstable to polar solvents and certain lyes.

Conveying tubing made of high-quality mixed polymers of fluorinated hydrocarbons

Very good chemical resistance

Very good heat resistance

Very good resistance to effects of ozone, oxygen, aging, and weather

Flame-resistant

Smooth surface

Low abrasion

Highest mechanical strength

Maximum dimensional stability

Material: FPM (fluorinated rubber)

Colour: black

Temperature range: -20 to +200 °C, for a short period +250 °C

Permeability: extremely low, nearly gas-tight

Dielectric constant: 15 at 50 Hz

Volume Resistivity: 2 x 1013 Ohm x cm

Abrasion: 190 mm3

Tolerances: DIN ISO 3302-1 E2

Item Image Inside Ø
mm
 Außen-Ø
mm
 Wandstärke
mm
 Farbcode Einheit
Stück
 Price
Euro* 		Buy
43787
0,51 2,35 0,92 orange/gelb 6 480.00
43788
0,64 2,48 0,92 orange/weiß 6 480.00
43789
0,76 2,6 0,92 schwarz 6 480.00
43790
0,89 2,73 0,92 orange 6 480.00
43791
1,02 2,86 0,92 weiß 6 480.00
43792
1,14 2,98 0,92 rot 6 480.00
43793
1,29 3,13 0,92 grau 6 480.00
43794
1,42 3,26 0,92 gelb 6 480.00
43795
1,52 3,36 0,92 gelb/blau 6 480.00
43796
1,65 3,49 0,92 blau 6 480.00
43797
1,85 3,69 0,92 grün 6 480.00
43798
2,06 3,74 0,84 violett 6 480.00
43799
2,29 3,97 0,84 violett/schwarz 6 480.00
43800
2,54 4,22 0,84 violett/orange 6 480.00
43801
2,79 4,47 0,84 violett/weiß 6 480.00
