FPM Plate - Shore 75°

Product specification Very good resistance to ozone and oxygen Very good resistance to aging... more

Product specification

Very good resistance to ozone and oxygen

Very good resistance to aging and weather

High flame resistance

Highest temperature resistance

Very good thermal resistance

Sulfur-free

Moderate elongation at break

Relative abrasion resistance

Limited flexibility in cold

Very good chemical resistance to petrol, oil, acids, conditionally resistant to alkalis

Chemical features:

FPM are copolymers of highest quality made of fluorinated hydrocarbons.

Fluorinated rubber belongs to the most expensive elastomers and is used exclusively in chemical-technical application areas according to its highly qualified features.

Its outstanding thermal and chemical properties are unrenounceable especially in the sealing technique.

Basically, a difference is made between copolymer made of vinylidene fluoride with hexafluoro propylene and FPM-terpolymer with improved chemical resistance and flexibility in the cold.

Technical specification

Material: FPM (fluorinated rubber polymer)

Colour: black

Shore hardness A: 75° ±5° (DIN 53505)

Temperature range: -10 to +230 °C, for a short time +275 °C

Density: 1.85 - 2.05 g/cm3

Elongation at break: 165 - 235 % (DIN 53504)

Tearing strength: 9 MPa (DIN 53504)

Compression set: 25 % at +200 °C / 24 h

Tolerance: DIN ISO 3302-1 E2

Flammability rating: UL 94 V-0

Burning behaviour: Self-extinguishing

Specific features: bisphenol-crosslinked, electrical isolation, E10-conform, E85-conform (Bioethanol)

Regulations: FDA-conform

No additional information available.
Item Image Thickness
mm
Abmessung
mm
Einheit
Stück
Price
Euro*
Buy
40255
1 200 x 200 1 135.00
40257
1,5 200 x 200 1 215.00
40259
2 200 x 200 1 222.00
40261
3 200 x 200 1 256.00
40263
4 200 x 200 1 378.00
40256
1 300 x 300 1 225.00
40258
1,5 300 x 300 1 282.00
40260
2 300 x 300 1 306.00
40262
3 300 x 300 1 370.00
40264
4 300 x 300 1 480.00
19894
0,5 500 x 500 1 214.00
19895
1 500 x 500 1 244.00
19896
1,5 500 x 500 1 304.00
19897
2 500 x 500 1 334.00
19899
3 500 x 500 1 427.00
19900
4 500 x 500 1 482.00
19901
5 500 x 500 1 536.00
19902
6 500 x 500 1 596.00
19903
0,5 1000 x 1000 1 433.00
19904
1 1000 x 1000 1 516.00
19905
1,5 1000 x 1000 1 647.00
19906
2 1000 x 1000 1 763.00
19907
3 1000 x 1000 1 1,127.00
19908
4 1000 x 1000 1 1,318.00
19909
5 1000 x 1000 1 1,842.00
19910
6 1000 x 1000 1 2,021.00
