Product specification
Good elastic behavior
Average mechanical stability
Good abrasion resistance
Good thermal resistance
Good resistance to aging, weather, and ozone
High flame resistance
Good resistance to diluted acids and alkalis, limited resistance to mineral oils
Poor resistance to solvents and steam
Chemical features:
CR is a all-round synthetic rubber basing on polychloroprene.
Chloroprene rubber is vulcanized in different systems influencing parameters such as compression set, oil resistance, thermal resistance, and tendency to crystallization.
Use in contact with mineral oils possible, although swelling is stronger compared to NBR, depending on the respective compound specification.
Less suitable for outdoor applications.
Technical specification
Material: CR (chloroprene rubber)
Additive components: SBR (styrene-butadiene rubber)
Colour: white
Shore hardness A: 60° ±5° (DIN 53505)
Temperature range: -20 to +90 °C
Specific features: physiologically safe
Density: 1.46 g/cm3
Elongation at break: 550 %
Tearing strength: 6 MPa
Compression set: 25 % at +72 °C / 23 h
Tolerance: DIN ISO 3302-1 E2
| Item | Image |
Thickness mm
|
Abmessung mm
|
Einheit Stück
|
Price Euro* |
Buy |
|---|---|---|---|---|---|---|
| 19601 |
|
1,5 | 700 x 700 | 1 | 85.00 | |
| 19602 |
|
2 | 700 x 700 | 1 | 97.00 | |
| 19603 |
|
3 | 700 x 700 | 1 | 117.00 | |
| 19604 |
|
4 | 700 x 700 | 1 | 139.00 | |
| 19605 |
|
5 | 700 x 700 | 1 | 162.00 | |
| 19606 |
|
6 | 700 x 700 | 1 | 185.00 | |
| 19608 |
|
1,5 | 1400 x 1400 | 1 | 154.00 | |
| 19609 |
|
2 | 1400 x 1400 | 1 | 182.00 | |
| 19610 |
|
3 | 1400 x 1400 | 1 | 208.00 | |
| 19611 |
|
4 | 1400 x 1400 | 1 | 257.00 | |
| 19612 |
|
5 | 1400 x 1400 | 1 | 288.00 | |
| 19613 |
|
6 | 1400 x 1400 | 1 | 342.00 | |
