Mini Screw-in Connector with male thread UNF 1/4"-28

Mini Screw-in Connector with male thread UNF 1/4&quot;-28

Product specification Tubing connection on one side, UNF 1/4"-28 external thread on the... more

Close menu

Product specification

Tubing connection on one side, UNF 1/4"-28 external thread on the other side, for flexible tubing

General Information PA 6.6 (polyamide 6.6, nylon) Colour: white Temperature... more

Close menu

General Information

PA 6.6 (polyamide 6.6, nylon)

Colour: white

Temperature range: -40 to +115 °C

Max. operating pressure: 3 bar at +20 °C

Yellowing and reduction of strength depending on temperature and interaction time

Regulatory compliance to RoHS, BPA, DEHP

Good sterilization with autoclave, ethylene oxide and gamma radiation (may discolour to brownish hue)

PP (polypropylene)

Colour: natural

Temperature range: -5 to +120 °C

Max. operating pressure: 3 bar at +20 °C

Regulatory compliance to USP Class VI, FDA 21 CFR 177.1520, RoHS, BPA, DEHP, ADI-free

Good sterilization with ethylene oxide and gamma radiation (bis 6 Mrads; may discolor the material with repeated sterilization), autoclave limited to short term +121 °C for 20 min.

PVDF (Polyvinylidene fluoride)

Colour: natural

Temperature range: -40 to +140 °C

Max. operating pressure: 3 bar at +20 °C

Regulatory compliance to USP Class VI, FDA 21 CFR 177.2510, RoHS, BPA-free, DEHP-free, ADI-free

PVDF is non-toxic and can be used in the food industry without hesitation. According to FDA (USA), the material is physiologically safe. It is as unsuitable as glass for propagation and growing of microorganisms.

Excellent sterilization with autoclave, ethylene oxide and gamma radiation (will discolour to brownish hue)

Item	Image	Tubing inside Ø mm	Außengewinde	Werkstoff	Farbe	Einheit Stück	Price Euro*
29006	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	1,6	UNF 1/4"-28	PA 6.6	weiß	15	52.00
29007	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	1,6	UNF 1/4"-28	PA 6.6	schwarz	15	52.00
29008	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	1,6	UNF 1/4"-28	PP	natur	10	42.00
29009	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	1,6	UNF 1/4"-28	PVDF	natur	5	50.00
29012	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	2,4	UNF 1/4"-28	PP	natur	10	42.00
29013	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	2,4	UNF 1/4"-28	PVDF	natur	5	50.00
29014	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	3,2	UNF 1/4"-28	PA 6.6	weiß	15	52.00
29015	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	3,2	UNF 1/4"-28	PA 6.6	schwarz	15	52.00
29016	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	3,2	UNF 1/4"-28	PP	natur	10	42.00
29017	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	3,2	UNF 1/4"-28	PVDF	natur	5	50.00
29020	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	4	UNF 1/4"-28	PP	natur	10	42.00
29021	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	4	UNF 1/4"-28	PVDF	natur	5	50.00
29022	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	4,8	UNF 1/4"-28	PA 6.6	weiß	15	52.00
29023	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	4,8	UNF 1/4"-28	PA 6.6	schwarz	15	52.00
29025	Mini Screw-in Connector with male thread UNF 1/4"-28 Mini Screw-in Connector with male thread UNF 1/4"-28	4,8	UNF 1/4"-28	PVDF	natur	5	50.00
