Filter Holder made of PFA

Application area Filter unit for individual problem solutions and for fixed mounting in... more

Application area

Filter unit for individual problem solutions and for fixed mounting in complete systems.

Product specification

Resistant to strongest organic and inorganic compounds.

The highest permissive loadable temperature is +288 °C with approx. 2,000 operating hours; with more than 2000 operating hours the loadable temperature is decreased to +260 °C.

PFA is non-toxic and is safely to be used in the food processing industry. It is as unsuited as glass for propagation and growth of microorganisms.

Available are 2 types with diameters 47 and 50 mm with different connecting combinations each. The respective size (diameter) is colour-coded. The coloured outer edge of the top is 25 % glass fibre reinforced providing higher material stability.

Specification of connecting combinations:

1 inlet/outlet tube 3/8" outer diameter (OD)

2 inlet with tube 3/8" OD; outlet with clamp fitting for tubing 1/4" OD

3 inlet with tube 3/8" OD, outlet with clamp fitting for tubing 3/8" OD

4 inlet with clamp fitting for tubing 1/4" OD; outlet with tube 3/8" OD

5 inlet with clamp fitting for tubing 3/8" OD; outlet with tube 3/8" OD

6 inlet with clamp fitting for tubing 1/4" OD; outlet with clamp fitting for tubing 1/4" OD

7 inlet with clamp fitting for tubing 3/8" OD; outlet with clamp fitting for tubing 3/8" OD

8 inlet/outlet tube 1/2" OD

9 inlet with tube 1/2" OD; outlet with clamp fitting for tubing 1/4" OD

10 inlet with tube 1/2" OD; outlet with clamp fitting for tubing 3/8" OD

11 inlet with clamp fitting for tubing 1/4" OD; outlet with tube 1/2" OD

12 inlet with clamp fitting for tubing 3/8" OD; outlet with tube 1/2" OD

No additional information available.
Item Image Type Ø filter
mm
Max. op. pressure1
bar
Colour Unit
piece
Price
Euro*
Buy
72499
Filter Holder made of PFA Filter Holder made of PFA
1 47 1,7 orange 1 202.00
72500
Filter Holder made of PFA Filter Holder made of PFA
2 47 1,7 orange 1 215.00
72501
Filter Holder made of PFA Filter Holder made of PFA
3 47 1,7 orange 1 215.00
72502
Filter Holder made of PFA Filter Holder made of PFA
4 47 1,7 orange 1 215.00
72503
Filter Holder made of PFA Filter Holder made of PFA
5 47 1,7 orange 1 222.00
72504
Filter Holder made of PFA Filter Holder made of PFA
Filter Holder made of PFA Filter Holder made of PFA
6 47 1,7 orange 1 228.00
72505
Filter Holder made of PFA Filter Holder made of PFA
7 47 1,7 orange 1 234.00
72506
Filter Holder made of PFA Filter Holder made of PFA
1 50 1,7 grün 1 215.00
72507
Filter Holder made of PFA Filter Holder made of PFA
8 50 1,7 grün 1 215.00
72508
Filter Holder made of PFA Filter Holder made of PFA
2 50 1,7 grün 1 215.00
72509
Filter Holder made of PFA Filter Holder made of PFA
9 50 1,7 grün 1 215.00
72510
Filter Holder made of PFA Filter Holder made of PFA
3 50 1,7 grün 1 215.00
72511
Filter Holder made of PFA Filter Holder made of PFA
10 50 1,7 grün 1 222.00
72512
Filter Holder made of PFA Filter Holder made of PFA
4 50 1,7 grün 1 222.00
72513
Filter Holder made of PFA Filter Holder made of PFA
11 50 1,7 grün 1 222.00
72514
Filter Holder made of PFA Filter Holder made of PFA
5 50 1,7 grün 1 228.00
72515
Filter Holder made of PFA Filter Holder made of PFA
12 50 1,7 grün 1 234.00
72535
Filter Holder made of PFA Filter Holder made of PFA
Filter Holder made of PFA Filter Holder made of PFA
6 50 1,7 grün 1 234.00
72536
Filter Holder made of PFA Filter Holder made of PFA
7 50 1,7 grün 1 240.00
72516
Filter Holder made of PFA Filter Holder made of PFA
1 47 4,5 schwarz 1 215.00
72517
Filter Holder made of PFA Filter Holder made of PFA
2 47 4,5 schwarz 1 215.00
72518
Filter Holder made of PFA Filter Holder made of PFA
3 47 4,5 schwarz 1 222.00
72519
Filter Holder made of PFA Filter Holder made of PFA
4 47 4,5 schwarz 1 215.00
72520
Filter Holder made of PFA Filter Holder made of PFA
5 47 4,5 schwarz 1 215.00
72521
Filter Holder made of PFA Filter Holder made of PFA
Filter Holder made of PFA Filter Holder made of PFA
6 47 4,5 schwarz 1 228.00
72522
Filter Holder made of PFA Filter Holder made of PFA
7 47 4,5 schwarz 1 234.00
72523
Filter Holder made of PFA Filter Holder made of PFA
1 50 4,5 braun 1 215.00
72524
Filter Holder made of PFA Filter Holder made of PFA
8 50 4,5 braun 1 215.00
72525
Filter Holder made of PFA Filter Holder made of PFA
2 50 4,5 braun 1 222.00
72526
Filter Holder made of PFA Filter Holder made of PFA
9 50 4,5 braun 1 228.00
72527
Filter Holder made of PFA Filter Holder made of PFA
3 50 4,5 braun 1 228.00
72528
Filter Holder made of PFA Filter Holder made of PFA
10 50 4,5 braun 1 234.00
72529
Filter Holder made of PFA Filter Holder made of PFA
4 50 4,5 braun 1 222.00
72530
Filter Holder made of PFA Filter Holder made of PFA
11 50 4,5 braun 1 222.00
72531
Filter Holder made of PFA Filter Holder made of PFA
5 50 4,5 braun 1 222.00
72532
Filter Holder made of PFA Filter Holder made of PFA
12 50 4,5 braun 1 234.00
72533
Filter Holder made of PFA Filter Holder made of PFA
Filter Holder made of PFA Filter Holder made of PFA
6 50 4,5 braun 1 240.00
72534
Filter Holder made of PFA Filter Holder made of PFA
7 50 4,5 braun 1 246.00
