Foam Rubber Sheet made of CR - with skin

Product specification Excellent resistance to weather, aging and ozone Remarkable... more

Close menu

Product specification

Excellent resistance to weather, aging and ozone

Remarkable temperature resistance, also for a short time!

Good mechanical stability

High flame resistance

Technical specification

Material: CR (chloroprene rubber)

Colour: light-beige

Temperature range: -40 to +110 °C, for a short time +140 °C

Density: 700 to 1,000 kg/m³

Compression set:

at +23 °C / 72 h: appr. 10 % (DIN 53572)

at +70 °C / 22 h: appr. 22 % (DIN 53572)

Applied pressure at load 1 kP/cm2: approx. 25 - 35 %

Inflammability: self-extinguishing

Design: with skin on both sides and fine pattern, but open-pored

General Information Foam rubber has a mixed cell structure with mostly open cells and a dense... more

Close menu

General Information

Foam rubber has a mixed cell structure with mostly open cells and a dense outer skin. It is used in many ways as a sealing material in the form of round cords, square profiles, plates or moldings.

Since open-celled, these materials can therefore absorb liquids.

The surface of sponge rubber profiles and seals is better protected from external influences than with cellular rubber due to the dense, robust and elastic outer skin.

However, if the surface is damaged, then the foam rubber seal with the open-cell structure, through the capillary action with aqueous medium can soak.

Foam rubber and cellular rubber are made from the same raw materials, often EPDM, CR, NR, NBR or SBR. Due to different manufacturing processes, however, the material structure of sponge rubber and cellular rubber differs fundamentally.

Item	Thickness mm	Toleranz mm	Abmessung mm	Einheit Stück	Price Euro*
332105	2	±0,5	250 x 250	1	71.00
332106	2	±0,5	500 x 500	1	140.00
332107	2	±0,5	1000 x 1000	1	279.00
332108	3	±0,5	250 x 250	1	75.00
332109	3	±0,5	500 x 500	1	152.00
332110	3	±0,5	1000 x 1000	1	307.00
332111	4	±0,6	250 x 250	1	78.00
332112	4	±0,6	500 x 500	1	157.00
332113	4	±0,6	1000 x 1000	1	315.00
332114	5	±0,7	250 x 250	1	82.00
332115	5	±0,7	500 x 500	1	165.00
332116	5	±0,7	1000 x 1000	1	332.00
332117	6	±0,7	250 x 250	1	90.00
332118	6	±0,7	500 x 500	1	180.00
332119	6	±0,7	1000 x 1000	1	360.00
332120	8	±0,8	250 x 250	1	90.00
332121	8	±0,8	500 x 500	1	182.00
332122	8	±0,8	1000 x 1000	1	366.00
332123	10	±0,8	250 x 250	1	93.00
332124	10	±0,8	500 x 500	1	187.00
332125	10	±0,8	1000 x 1000	1	373.00
332126	12	±0,9	250 x 250	1	97.00
332127	12	±0,9	500 x 500	1	193.00
332128	12	±0,9	1000 x 1000	1	388.00
332129	15	±1,0	250 x 250	1	103.00
332130	15	±1,0	500 x 500	1	206.00
332131	15	±1,0	1000 x 1000	1	409.00
332132	20	±1,0	250 x 250	1	114.00
332133	20	±1,0	500 x 500	1	227.00
332134	20	±1,0	1000 x 1000	1	454.00
