High-Tech Gas Delivery Pump

High-Tech Gas Delivery Pump
Application area Delivery and metering of all kinds of gases. Product specification... more

Application area

Delivery and metering of all kinds of gases.

Product specification

Valveless low-pressure single-piston pump system FMI® with robust, ball-bearing low-voltage driving motor, self-cooling; for delivery of all kinds of gases; conveying line connections to be chosen optionally. Precisely adjustable delivery rates by mechanical delivery stroke alteration; suitable for continuous duty.

Technical specification

Material pump head:

Piston: stainless steel 1.4401 (SS 316)

Cylinder: graphite (sinter carbon)

Housing: fluorocarbon material PVDF

Connection: fluorocarbon material PVDF

Drive system:

Voltage: 220 V~ / 50-60 Hz

Gear reduction: 6; 20; 50; 150 or 400 rpm

Precision of delivery: better than 1.0 %

Pipe connection: compression-type fitting for pipes OD 6.4 mm, reducible with adapter

Max. operating pressure: 6.9 bar

Dimension: 248 x 124 x 146 mm (L x W x H)

Weight: approx. 4.5 kg

No additional information available.
Item Image Delivery volume
ml/stroke
Max. op. pressure1
bar
Motordrehzahl
UpM
Unit
piece
Price
Euro*
Buy
58341
0,15 6,9 6 1 2,409.00
58342
0,48 1,4 6 1 2,179.00
58343
1,92 5,2 6 1 1,984.00
58344
4,32 3,5 6 1 1,984.00
58345
0,5 6,9 20 1 2,409.00
58346
1,6 1,4 20 1 2,179.00
58347
6,4 3,5 20 1 1,984.00
58348
14,4 2,8 20 1 1,984.00
58349
1,25 6,9 50 1 2,409.00
58350
4 6,9 50 1 2,179.00
190611
16 2,8 50 1 1,984.00
190621
36 2,1 50 1 1,984.00
190631
3,75 6,9 150 1 2,409.00
190641
12 6,9 150 1 2,179.00
190651
48 2,1 150 1 1,984.00
190661
108 1,4 150 1 1,984.00
190671
10 6,9 400 1 2,409.00
190681
32 6,9 400 1 2,179.00
190691
128 1,4 400 1 1,984.00
190701
288 0,7 400 1 1,984.00
