Adsorption Filter with Granular Activated Carbon

Application area Decolourization of fluids such as drinking water, process water and waste... more

Application area

Decolourization of fluids such as drinking water, process water and waste water, aqueous solutions, organic solvents and non-oxidizing acids.

Removal of adsorbable matters and contaminants out of fluids, vapours and gases.

Removal of flavours and odors out of fluids, gases and vapours.

Dechlorination of water.

Product specification

The filter cartridge is filled with granular activated carbon with a radial flow from bottom to top. Consequently it has a corresponding contact-time with the activated carbon.

Long contact time, high absorption.

A pre-filter made of polypropylene felt as well as a post-filter made of polypropylene melt-blow material with 20 μm filter ration retain the activated carbon and the activated carbon abrasion.

Construction support made of polystyrene.

FDA and NSF-certified.

The filter elements fit following housings:

Filter length 124 mm: item 94482

Filter length 248 mm: items 94445, 52851, 52853, 94479, 52863

Filter length 508 mm: items 52852, 12134

Technical specification

Filter medium: Granular activated carbon

Core support: Polystyrene

Adapter and tubular support: Polystyrene

Gasket: NBR

Pre-filter: Polyester felt

Post-filter: PP Melt-blow material 20 μm

Flow rates:

1.9 l/min at 0.2 bar

3.8 l/min at 0.5 bar

7.6 l/min at 1.1 bar

Max. temperature: +50 °C

No additional information available.
Item Image Length
124 30 70 1 145.00
248 30 70 1 194.00
508 30 70 1 288.00
