Timing Belts HTD (open-length)

Timing Belts HTD (open-length)
Product specification Open-end timing belts HTD timing belts cannot be welded Available in... more

Product specification

Open-end timing belts

HTD timing belts cannot be welded

Available in whole-number meter lengths in one piece from 1 metre up to max. roll length (30 m)

General Information Use for power transmission, bridging of large centre distances and... more

General Information

Use for power transmission, bridging of large centre distances and alteration of transmission ratios.

For various applications in machinery and plant engineering, in laboratory technology, in industrial and food processing plants, as well as in model making.

Quiet operation and synchronous transmission of power

Maintenance-free. Lubrication is not required.

High efficiency up to 98 %

Belt pre-tension is required

T timing belts made of polyurethane with pitch 2.5 or 5 mm. Light-coloured belts with little abrasion. For standard applications in machine building and food technology, to be used on T pulleys.

AT timing belts made of polyurethane with pitch 5 mm. Reinforced type for high loads with low space requirements. To be used on AT pulleys.

HTD timing belts made of neoprene with pitch 3, 5 or 8 mm. For high power transmission even at high speeds.

Black belts with dark abrasion (not for laboratory operations / food processing). To be used on HTD pulleys.

Notes on mounting and usage:

Pulleys must be aligned (precisely positioned)

The belt tension has to be adjusted (The overall sum of tensioning and peripheral force must not exceed the permitted tensile force of the belt.)

At least one pulley must be equipped with flanges.

And at least 6 teeth should be engaged at any time.

Timing belt drives run without lubrication.

General Information HTD

HTD (High Torque Drive) timing belts with semi-circular teeth profile with metric dimensions, pitch 3, 5 or 8 mm

Timing belts available as endless timing belts (closed-loop) or as open-length types (open-end, cannot be welded)

High load transmission even at high speeds

HTD timing belts only run on HTD pulleys

Pulleys available for HTD-3M made of aluminium, for HTD-5M made of steel (from 44 teeth made of aluminium), for HTD-8M made of steel (from 80 teeth made of grey cast iron)

HTD drives are not backlash-free

Semi-circular teeth profile for a more constant progress of stress

Contact surface lined with PA 6.6 (nylon) reinforcement for minimizing of abrasion

Material: neoprene, black, with tensile member of glass-fibre

Temperature range: -20 to +100 °C

Pitch: 3M: 3 mm; 5M: 5 mm; 8M: 8 mm

Overall height: 3M: 2.4 mm; 5M: 3.6 mm; 8M: 5.6 mm

Tooth height: 3M: 1.2 mm; 5M: 2.1 mm; 8M: 3.4 mm

Tensile force: 3M: 100 N; 5M: 208 N; 8M: 375 N (permissible tensile force at 10 mm belt width)

Item Image Profile Riemenbreite
mm
zul. Riemenzugkraft
N
passende Klemmplatte Gewicht
g/m
Einheit
m
Price
Euro*
Buy
702109
HTD-3M 9 90 27 2 58.00
702110
HTD-3M 9 90 27 6 129.00
702111
HTD-3M 15 150 44 2 80.00
702112
HTD-3M 15 150 44 6 174.00
7021131
HTD-5M 10 208 702715 37 2 58.00
7021141
HTD-5M 10 208 702716 37 6 122.00
702115
HTD-5M 15 312 702717 61 2 84.00
702116
HTD-5M 15 312 702718 61 6 180.00
702117
HTD-5M 25 520 702719 102 2 122.00
702118
HTD-5M 25 520 702720 102 6 277.00
702119
HTD-8M 20 750 702721 128 2 127.00
702120
HTD-8M 20 750 702722 128 6 283.00
702121
HTD-8M 30 1.125 702723 192 1 82.00
702122
HTD-8M 30 1.125 702724 192 3 183.00
702123
HTD-8M 50 1.875 702725 320 1 137.00
702124
HTD-8M 50 1.875 702726 320 3 305.00
