Product specification
Liner:
Very high abrasion resistance
High tearing strength
High shock strength
Very good elastic behaviour
Jacket:
Extremely high abrasion resistance
Good thermal resistance and resistance to aging
Resistant to weak acids and alkalis
Technical specification
Material:
Liner: NR (natural rubber)
Jacket: SBR (styrene-butadiene rubber)
Colour: black, smooth
Temperature range: -30 to +80 °C
Max. operating pressure: 12 bar
Bursting pressure: 36 bar at +20 °C
Leakage resistance: <106 Ohm
Abrasion: 60 - 70 mm3 according to DIN 53516
| Item | Image |
Inside Ø mm
|
Außen-Ø mm
|
Wandstärke mm
|
Einheit m
|
Price Euro* | Buy |
|---|
Item
|
|
Inside Ø mm
|
Außen-Ø mm
|
Wandstärke mm
|
Einheit m
|
Price Euro* |
Buy
|
|---|---|---|---|---|---|---|---|
| 306354 |
|
13 | 27 | 7 | 3 | 172.00 | |
| 306355 |
|
13 | 27 | 7 | 5 | 257.00 | |
| 306356 |
|
19 | 33 | 7 | 3 | 180.00 | |
| 306357 |
|
19 | 33 | 7 | 5 | 274.00 | |
| 306358 |
|
25 | 39 | 7 | 3 | 200.00 | |
| 306359 |
|
25 | 39 | 7 | 5 | 307.00 | |
| 306360 |
|
32 | 48 | 8 | 3 | 210.00 | |
| 306361 |
|
32 | 48 | 8 | 5 | 319.00 | |
| 306362 |
|
38 | 55 | 8,5 | 3 | 283.00 | |
| 306363 |
|
38 | 55 | 8,5 | 5 | 426.00 | |
| 306364 |
|
42 | 60 | 9 | 1 | 125.00 | |
| 306365 |
|
42 | 60 | 9 | 3 | 324.00 | |
| 306366 |
|
50 | 70 | 10 | 1 | 155.00 | |
| 306367 |
|
50 | 70 | 10 | 3 | 424.00 |
