PUR Spiral Chemical Tubing for Analytic Technology

Product specification Very good mechanical stability, tearing-resistant Very good elastic... more

Product specification

Very good mechanical stability, tearing-resistant

Very good elastic behaviour comparable to soft rubber, thus outstanding flexibility

Flexible also at -40 °C

Smallest bending radius, especially resistant to kinking and tearing

Very high resistance to abrasion

Good resistance to aging and weather

Calibrated according to CETOP standard

Good chemical resistance to gasoline, cyclohexane, diesel oil, isooctane, kerosine, and aqueous salt solutions.

UV-resistant

Technical specification

Material: PUR (polyurethane)

Colour: natural/black/white/red/yellow

Shore hardness A: 98° ±5°

Temperature range: -40 to +80 °C, for a short time +120 °C

Max. operating pressure: 10 bar at +20 °C

Bursting pressure: 30 bar at +20 °C

No additional information available.

Item	Inside Ø mm	Außen-Ø mm	Spiral-Ø innen mm	Spiral-Ø außen mm	Arbeitslänge m	Farbe	Einheit Stück	Price Euro*
28369	1,6	3,2	14	19	2,5	natur	1	55.00
28371	1,6	3,2	14	19	2,5	weiß	1	55.00
28372	1,6	3,2	14	19	2,5	rot	1	55.00
28374	1,6	3,2	14	19	5	natur	1	86.00
28375	1,6	3,2	14	19	5	schwarz	1	86.00
28376	2	4	15	22	2,5	natur	1	66.00
28377	2,4	4	15	22	2,5	natur	1	66.00
28379	3,2	6,4	25	32	2,5	schwarz	1	90.00
28380	3,2	6,4	25	32	2,5	weiß	1	90.00
28381	3,2	6,4	25	32	2,5	rot	1	90.00
28382	3,2	6,4	25	32	2,5	gelb	1	90.00
28383	3,2	6,4	25	32	5	natur	1	148.00
28388	6,4	9,5	51	63	2,5	schwarz	1	125.00
28389	6,4	9,5	51	63	2,5	rot	1	125.00
28390	6,4	9,5	51	63	2,5	gelb	1	125.00
28392	6,4	9,5	51	63	5	schwarz	1	200.00
