PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free

Product specification Female coupling parts with shut-off valve for prevention of medium... more

Product specification

Female coupling parts with shut-off valve for prevention of medium backflow

Versions with hose nozzle, pipe connection or internal/external thread

Can be combined exclusively with all male coupling parts of nominal width 9.5 mm, metal-free

Metal-free flow path, the medium does not come into contact with metal

General Information Quick-Disconnect Coupling THOMAFLUID ® -quick-disconnect coupling... more

General Information Quick-Disconnect Coupling

THOMAFLUID®-quick-disconnect coupling systems are excellently suited for connecting and disconnecting of tubes, apparatuses etc. The quick-disconnect couplings are easy to operate, connecting and disconnecting can be done by one hand. The coupling is self-locking when the nipple is plugged-in. For disconnection a short thumb pressure on the lock is sufficient to pull out the nipple easily. All nipples are fitted with an easily interchangeable, reliably sealing O-ring.

A complete operable THOMAFLUID®-quick-disconnect coupling system consists of a coupling part and a nipple part, both parts may be fitted with valves. A complete quick-disconnect coupling system locking at one side consists of a coupling part with shut-off and a nipple part with port, or a coupling part with port and a nipple part with shut-off. To get a coupling locking on both sides, a coupling part as well as a nipple part, both with shut-off, have to be obtained.

General Information PP

Use for microbiological testing equipment, electroplating liquids, sterilisation equipment, water pollution analysis.

PP allows higher chemical resistances for more demanding applications compared to POM. The coupling parts are also sterilizable with gamma rays.

Resistant to oils, petrol, acids etc.

General Information 9.5 mm nominal width

Use in the areas of industrial laundries, battery filling systems, dry cleaning or with deionized/ultra-pure water.

Couplings made of robust glass fiber reinforced polypropylene with seals made of EPDM. Due to the metal-free flow path the couplings are corrosion-free and provide a broad chemical resistance and an exceptionally high flow rate with low turbulences.

The couplings can be connected and disconnected with one hand by using the release key.

No spillage under increased pressure, therefore the couplings provide enhanced operator safety even with more aggressive chemicals.

Material:

Valve body: glass fiber reinforced polypropylene

Seals: EPDM

Valve spring (not medium-contacting): stainless steel 316

Thumb latch: glass fiber reinforced polypropylene

Cap nut: white polypropylene

Color: dark gray

Nominal width: 9.5 mm

Plug diameter: approx. 30 mm

Temperature range: 0 to +49 °C

Max. operating pressure: vacuum to 8.3 bar at +20 °C

Lubricants: Krytox® PFPE (chemically neutral)

Spillage: 0.03 ml/disconnect

Inclusion: 0.42 ml/disconnect

Item Image Connection Ventil Länge
mm
Einheit
Stück
Price
Euro*
Buy
43494
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
I-Gewinde NPT 3/8" mit 94 1 156.00
43495
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
A-Gewinde BSPT 3/8" mit 93 1 143.00
43496
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
A-Gewinde NPT 1/2" mit 97 1 143.00
43497
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
A-Gewinde NPT 3/4" mit 102 1 156.00
43502
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
Tülle 15,9 mm mit 99 1 143.00
43503
PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free PP Quick-Disconnect Coupling, NW 9.5 mm - metal-free
Tülle 19,0 mm mit 99 1 150.00
