High-Pure Elbow Pipe Connector with Female Thread made of PFA
Item |
Pipe outside Ø mm
|
Rohr Außen-Ø Zoll
|
Innengewinde |
D mm
|
l1 mm
|
L1 mm
|
L2 mm
|
Einheit Stück
|
Price Euro* |
Buy |
---|---|---|---|---|---|---|---|---|---|---|
304749 | 4 | G 1/8" | 13 | 10 | 26 | 17 | 1 | 83.00 | ||
304750 | 4 | G 1/4" | 20 | 15 | 26 | 20 | 1 | 90.00 | ||
304751 | 4 | G 3/8" | 20 | 15 | 28 | 20 | 1 | 107.00 | ||
304752 | 4 | G 1/2" | 25 | 16 | 31 | 20 | 1 | 120.00 | ||
304753 | 6 | G 1/8" | 15 | 10 | 36 | 17 | 1 | 90.00 | ||
304754 | 6 | G 1/4" | 20 | 15 | 39 | 20 | 1 | 93.00 | ||
304755 | 6 | G 3/8" | 25 | 15 | 42 | 20 | 1 | 128.00 | ||
304756 | 6 | G 1/2" | 30 | 16 | 44 | 20 | 1 | 138.00 | ||
304757 | 8 | G 1/8" | 15 | 10 | 36 | 17 | 1 | 101.00 | ||
304758 | 8 | G 1/4" | 20 | 15 | 39 | 20 | 1 | 107.00 | ||
304759 | 8 | G 3/8" | 25 | 15 | 42 | 20 | 1 | 134.00 | ||
304760 | 8 | G 1/2" | 30 | 16 | 44 | 20 | 1 | 158.00 | ||
304761 | 10 | G 1/8" | 20 | 10 | 42 | 20 | 1 | 107.00 | ||
304762 | 10 | G 1/4" | 20 | 15 | 42 | 23 | 1 | 114.00 | ||
304763 | 10 | G 3/8" | 25 | 15 | 45 | 23 | 1 | 144.00 | ||
304764 | 10 | G 1/2" | 30 | 16 | 47 | 23 | 1 | 162.00 | ||
304765 | 12 | G 1/8" | 20 | 10 | 45 | 20 | 1 | 114.00 | ||
304766 | 12 | G 1/4" | 20 | 15 | 45 | 23 | 1 | 125.00 | ||
304767 | 12 | G 3/8" | 25 | 15 | 48 | 23 | 1 | 152.00 | ||
304768 | 12 | G 1/2" | 30 | 16 | 50 | 23 | 1 | 168.00 | ||
304769 | 14 | G 1/8" | 25 | 10 | 48 | 20 | 1 | 128.00 | ||
304770 | 14 | G 1/4" | 25 | 15 | 48 | 23 | 1 | 141.00 | ||
304771 | 14 | G 3/8" | 25 | 15 | 48 | 23 | 1 | 168.00 | ||
304772 | 14 | G 1/2" | 30 | 16 | 50 | 23 | 1 | 195.00 | ||
304773 | 1/8" | G 1/8" | 13 | 10 | 26 | 17 | 1 | 83.00 | ||
304774 | 1/8" | G 1/4" | 20 | 15 | 26 | 20 | 1 | 90.00 | ||
304775 | 1/8" | G 3/8" | 20 | 15 | 28 | 20 | 1 | 107.00 | ||
304776 | 1/8" | G 1/2" | 25 | 16 | 31 | 20 | 1 | 120.00 | ||
304777 | 1/4" | G 1/8" | 15 | 10 | 36 | 17 | 1 | 90.00 | ||
304778 | 1/4" | G 1/4" | 20 | 15 | 39 | 20 | 1 | 93.00 | ||
304779 | 1/4" | G 3/8" | 25 | 15 | 42 | 20 | 1 | 128.00 | ||
304780 | 1/4" | G 1/2" | 30 | 16 | 44 | 20 | 1 | 138.00 | ||
304781 | 3/8" | G 1/8" | 20 | 10 | 42 | 20 | 1 | 107.00 | ||
304782 | 3/8" | G 1/4" | 20 | 15 | 42 | 23 | 1 | 114.00 | ||
304783 | 3/8" | G 3/8" | 25 | 15 | 45 | 23 | 1 | 149.00 | ||
304784 | 3/8" | G 1/2" | 30 | 16 | 47 | 23 | 1 | 162.00 | ||
304785 | 1/2" | G 1/8" | 20 | 10 | 45 | 20 | 1 | 114.00 | ||
304786 | 1/2" | G 1/4" | 20 | 15 | 45 | 23 | 1 | 125.00 | ||
304787 | 1/2" | G 3/8" | 25 | 15 | 48 | 23 | 1 | 152.00 | ||
304788 | 1/2" | G 1/2" | 30 | 16 | 50 | 23 | 1 | 168.00 |
